Serial Number

Type

Specification

1

Furnace Structure

Horizontal, single-chamber, with double-layer water cooling for the furnace body and door, and a front-opening structure. It consists of the furnace body, heating chamber, vacuum system, water cooling system, and electrical control and power supply system.

2

Maximum Temperature

1300℃

3

Working Area Dimensions

300 × 300 × 400 mm (taking a 300 × 400 mm substrate as an example, with a height of 300 mm)

4

Total Power

60KW

5

Power Frequency

50 / 60Hz

6

Power Voltage

Three-phase 380V (±10V)

7

External Dimensions

Approximately 1835 mm (L) × 2040 mm (H) × 1625 mm (D)
