Features and Applications：

● Femto plasma systems can be combined into various modular configurations.

● Femto plasma systems are primarily used in the following fields：analysis, archaeology, automotive, R&D, semiconductor technology, small-batch manufacturing, plastics technology, medical engineering, microsystems engineering, sensing technology, sterilization, and textile technology.

Specifications：

● Chamber Volume：Approximately 2-3 liters

● Housing：Desktop/Freestanding

    > Width 310-560 mm / 600 mm

    > Height 211-860 mm / 1700 mm

    > Depth 420-600 mm / 800 mm

● Plasma Generator：

    > 40 kHz / 0-100 W

    > 100 kHz / 0-500 W

    > 13.56 MHz / 0-200 W

    > 2.45 GHz / 0-300 W

● Control：

    > Semi-automatic

    > Basic computer

    > Full computer

● Application Examples：

    > Laboratory/Small Batch

    > Production

● Vacuum Chamber：

    > Round stainless steel cover：Ø 100 mm, D 278 mm

    > Stainless steel rectangular with hinged door：103 mm (W) x 103 mm (H) x 285 mm (D)

    > Aluminum rectangular with hinged door：110 mm (W) x 120 mm (H) x 300 mm (D)

    > Quartz glass (UHP) round with lid/hinged door：Ø 95 mm, D 280 mm

    > Borosilicate glass (HP) round with lid/hinged door：Ø 95 mm, D 280 mm

Brand：Diener / Germany, CE
