Serial Number

Type

Product Specifications

1

Furnace Chamber Dimensions

≥400 mm; Height ≥350 mm; Depth ≥600 mm

2

Operating Temperature

≤1450 ℃

3

Heating Rate

10℃ / min

4

Heating Element

High-purity silicon carbide rod

5

Furnace Chamber Material

Imported alumina fiber insulation refractory material

6

Temperature Control Accuracy

± 1℃

7

Furnace Chamber Mode

Parallel door, left opening

8

Control Mode

NBD-101E embedded operating system with English and Chinese compatible graphical interface, 7-inch color touch screen input, intelligent human-computer interaction mode, real-time heating power display, and non-linear temperature correction.

9

Ultimate Temperature

1500℃

10

Temperature Curve Settings

Up to 15 pre-stored sintering curves can be set, each with 30 time-temperature segments.

11

Operation Interface

Interactive Chinese and English graphical interface, color touch screen input, and intelligent human-computer interaction mode make the touch screen display more intuitive and convenient.

12

Temperature Curve Recording

Real-time monitoring, dynamic and realistic display of "time-temperature" curves, automatic storage and export support, support for curve fitting, and input using a digital correction system for high measurement accuracy.

13

Recording System

Remote control and recording system based on the Google Android operating platform.

14

Furnace Shell

Rust-proof steel plate + powder coating.

15

Electrical Certification

CE Certification

16

Electrical Specifications

220V / 50/60Hz  6KW

17

Dimensions

Height ≤ 1.0m; Length ≤ 70cm; Width ≤ 70cm
